DEUTZ KHD Common Rail Injector 0445020148 – Factory-Spec Replacement For TCD 2013



For diesel repair shops that regularly service Volvo excavators, Bomag rollers, or Deutz-Fahr tractors, the 0445020148 common rail injector is a high-turnover replacement part that directly impacts engine response, fuel economy, and emissions compliance. This injector, listed under DEUTZ KHD order numbers 04266349, 4266349, and 4267118, is a solenoid-actuated unit engineered for the TCD 2013 series 4.8L powerplant. It operates at rail pressures exceeding 1,600 bar, delivering precisely metered fuel doses across multiple injection events per cycle. For workshops, stocking the correct variant-distinguished by its Bosch and Deutz cross-references-eliminates comebacks tied to incorrect flow rates or mismatched ECU calibration parameters.



The 0445020148 is a CRIN2-16 solenoid-type injector featuring a 7mm nozzle with multiple orifices calibrated for the TCD 2013 combustion chamber geometry. Each unit carries a laser-etched tolerance classification code-typically a two‑character alphanumeric-that must be transcribed and entered into the engine ECU via diagnostic software post-installation. This coding step allows the control unit to compensate for minute flow variations between individual injectors, ensuring balanced cylinder contributions. The injector's internal hydraulic leakage is factory‑set below 30 ml/min under full load, a specification that preserves rail pressure stability across the rev range. The solenoid coil resistance falls within 0.2–0.3 Ω at 20°C, a value that workshops can quickly verify using a multimeter before condemning a unit.

This injector series is predominantly deployed across the DEUTZ TCD 2013 L4 2V engine platform. In the construction sector, it is the standard service part for Volvo EC240B, EC240C, and EC290B excavators, as well as Volvo G900 motor graders and L110E/L120F wheel loaders. Bomag applications include the BF 300 P paver and BW 177 D‑5 roller compactor. Agricultural fitments cover Deutz-Fahr Agrotron M620/M640 tractors and 6095 HTS combine harvesters. This broad cross‑model compatibility makes the 04266349 variant a lean‑inventory choice for independent shops serving mixed construction and farming fleets.



Proper seating of the 0445020148 injector demands a strict two‑stage clamping procedure. The hold‑down bolts must first be taken to 30 Nm, then rotated an additional 90 to 95 degrees using an angle gauge to achieve correct bolt stretch. The electrical connector nut is a low‑torque item specified at 1.5 Nm-overtightening here can crack the terminal housing. Always replace the copper sealing washer at the nozzle tip and thoroughly clean the cylinder head bore before insertion. DEUTZ KHD documentation permits reuse of hold‑down bolts for a maximum of three service cycles; beyond that, new bolts are mandatory to maintain clamp load integrity.



For the average diesel service bay, the 0445020148 represents a predictable consumable with a typical service interval of 12,000–15,000 operating hours in off‑highway use. Offering customers a choice between brand‑new OEM units and Bosch‑certified remanufactured exchanges gives workshops a pricing ladder that captures both premium and budget‑conscious clients. Remanufactured injectors-processed on Bosch‑licensed test benches with new control valves, nozzles, and springs-deliver the same hydraulic performance as fresh units at roughly 40–50% cost savings. The critical service differentiator, however, remains the tolerance code programming: failure to input this value into the ECU leads to uneven fuel trims, elevated smoke output, and reduced power. Educating customers on this requirement positions the shop as a knowledgeable provider and reduces the risk of post‑repair complaints.



Q1: Can I install this injector without any diagnostic tool, or is ECU coding absolutely mandatory?

Coding is mandatory. Without entering the tolerance code into the ECU, the engine control unit cannot adjust fuel trim for that cylinder, resulting in uneven running and increased emissions.

Q2: How do I distinguish order number 04266349 from 4266349 and 4267118 during parts lookup?

All three are DEUTZ KHD catalog numbers for the same injector. Different suffixes reflect minor packaging or supersession updates; any of them will correctly reference the 0445020148 Bosch unit.

Q3: What leak-off rate indicates a failing injector during a return-flow test?

A healthy injector shows leak‑off volumes under 25 ml/min at idle. Values exceeding 40 ml/min typically point to worn internal control valves and justify replacement.

Q4: Are remanufactured units guaranteed to match the flow curve of new injectors?

Yes, when remanufactured by Bosch‑licensed facilities, each unit is flow‑tested and calibrated to meet the original performance envelope defined for the 0445020148 specification.

Q5: Does replacing a single injector on a high‑hour engine create imbalance issues?

While not required, if the engine exceeds 12,000 hours, fitting a full set or a matched set of remanufactured injectors is recommended to ensure uniform cylinder output and avoid sequential failures.
