Bosch Valve

The fuel metering valvecircuit is open or short-circuited (the connection circuit to the ECU is faulty)
a.Turn on the fault light b. Generate corresponding fault codes: P0251 (Fuel metering valvedrive failure - open circuit), P0254 (Fuel metering valvedrive failure - short circuit to power supply), P0253 (Fuel metering valve drive failure - short circuit to ground), P160E (main relay 1 drive circuit failure - short circuit to power supply) or P160F (main relay 1 drive circuit failure - short circuit to ground); c. The controller increases the fuel supply of the high-pressure oil pump; d. The fuel pressure is too high and pressure relief The valve flushes open; e. The diagnostic instrument shows that the rail pressure is 700-760 bar; f. The engine speed is limited, and the throttle still works within the speed limit range.

The fuel metering valveand its connector are damaged (abnormal internal electrical connection failure)
Improper operations during use, maintenance, disassembly, transportation, and assembly may cause the fuel metering valve and its electrical connector to suffer from bumps, deformation, damage to the internal structure, or even leakage, leading to abnormal electrical connections.

The connector connection between the fuel metering valveand the ECU wiring harness is abnormal.
The connector pins are bent, broken, aged, worn, rusted, structurally failed, etc., as well as the connector has water ingress, resulting in abnormal connector connections.

Abnormal driving current and working status offuel metering valve
a.Turn on the fault light b. Generate the corresponding fault code: P025D (Fuel metering valveAD channel signal failure - voltage is extremely high), P025C (Fuel metering valveAD channel signal failure - voltage is extremely low), or P0252 (Fuel metering valve drive failure - over-temperature); c. The controller increases the fuel supply of the high-pressure oil pump; d. The fuel pressure is too high and the pressure relief valve opens; e. The diagnostic instrument shows that the rail pressure is 700-760 bar; f. The engine speed is limited, but the limit throttle still works within the speed range.

The fuel metering valveis stuck - stuck in the small opening position
a.The rail pressure is lower than the target value and the engine power is insufficient; b. The following fault codes may be generated: P1011 (rail pressure closed-loop control mode fault 0--rail pressure is lower than the target value), P0087 (rail pressure closed-loop control mode fault 3--rail pressure is lower), or P1019 (rail pressure closed-loop control mode fault 12--rail pressure is lower than the target value).

The fuel metering valveis stuck - stuck in the wide opening position
a.The rail pressure is higher than the target value. When the vehicle accelerates or goes uphill, the pressure relief valve is prone to open; b. The following fault code may be generated: P1013 (rail pressure closed-loop control mode fault 2--the rail pressure is higher than target value), P0088 (rail pressure closed-loop control mode fault 4--rail pressure is too high), P1014 (rail pressure closed-loop control mode fault 7--overrun mode fuel supply is too large) or P1018 (rail pressure closed-loop control mode fault 10 --The fuel supply is too large).

The fuel metering valvecore is worn and not sealed
When the car is going downhill or pushing backward, the pressure relief valve is prone to open.
